LT3505IMS8E#PBF Dual DC/DC Converter 3.6-36V Input 2.5A/1.6A Outputs 1.2MHz Freq Adjustable Sync Soft-Start 8-MSOP -40°C to 125°C Low Ripple

LT3505IMS8E#PBF Dual DC/DC Converter 3.6-36V Input 2.5A/1.6A Outputs 1.2MHz Freq Adjustable Sync Soft-Start 8-MSOP -40°C to 125°C Low Ripple

FEATURES

Wide Input Range: 3.6V to 36V Operating, 40V Maximum

Up to 1.2A Output Current

Resistor-Programmable Fixed-Frequency Operation from 200kHz to 3MHz

Output Adjustable Down to 780mV

Short-Circuit Robust

Uses Tiny Capacitors and Inductors

Soft-Start

Low Shutdown Current: <2µA

Low VCESAT Switch: 350mV at 1A

Thermally Enhanced, Low Profi le 3mm x 3mm DFN-8 and MSOP-8 Packages

APPLICATIONS

Automotive Battery Regulation

Industrial Control Supplies

Wall Transformer Regulation

Distributed Supply Regulation

Battery-Powered Equipment

DESCRIPTION

The LT®3505 is a current mode PWM step-down DC/DC converter with an internal 1.4A power switch. The wide operating input range of 3.6V to 36V (40V maximum) makes the LT3505 ideal for regulating power from a wide variety of sources, including unregulated wall transform ers, 24V industrial supplies and automotive batteries. The oscillator can be programmed for high frequency operation allowing the use of tiny, low cost external components or it can be programmed for lower frequency operation to maximize effi ciency.

Cycle-by-cycle current limit provides protection against shorted outputs and soft-start eliminates input current surge during start-up. The low current (<2µA) shutdown mode provides output disconnect, enabling easy power management in battery-powered systems.

INFORMATION

Drawing

Our advantage :

• High quality products --- our offers are 100% new and original, ROHS
• Competitive price --- good Purchase channels with good price.
• Professional service --- strict quality testing before the shipment, and perfect after-sales service after the purchase.
• Adequate inventory --- With the support of our strong Purchasing team,
• Fast delivery --- we will ship the goods within 1-3 working days after the payment confirmed.

be sure to meet your need for all kinds of components. ^_^


Product List
Supply a Series of Electronic Components, full range of semiconductors, active & passive Components.We can help you to get all for bom of the PCB,IN a word, you can get one-stop solution here,


The offers including:
Integrated Circuit, Memory ICs, Diode, Transistor , Capacitor, Resistor, Varistor, Fuse, Trimmer & Potentiometer, Transformer, Battery, Cable, Relay, Switch, Connector, Terminal Block, Crystal & Oscillator, Inductor, Sensor, Transformer, IGBT Driver, LED,LCD, Convertor, PCB (Printed Circuit Board),PCBA (PCB Assembly)

Strong in Brand:
Microchip, MAX, AD, TI, ATMEL, ST, ON, NS, Intersil, Winbond, Vishay, ISSI, Infineon, NEC, FAIRCHILD, OMRON,YAGEO, TDK, etc
